ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d

Place of Origin CHINA
Brand Name ROGOSTEEL
Certification ISO9001, ISO14001, OHSAS18001
Model Number SGCC, SPCC, DC51D, SGHC, A653
Minimum Order Quantity 25T
Price Negotiable
Packaging Details 2-layer anti-rust paper & waterproof paper; 1-layer PVC plastic board;
Delivery Time 30DAY
Payment Terms TT/LC
Supply Ability 1400000MT per year
Product Details
Items Name Pre-painted Galvanized Coil Steel Zinc Coating 40g
Size 0.2*1250mm Thickness 0.2-0.2mm
Width 650-1250mm Surface Treatment Galvanized,Coated,color Coated/galvanized,Printing / Filmed / Matte / Wrinkled,Skin Pass/Non Skin Pass
Technique Hot Dipped,Galvanized Steel / Galvalume Steel /Aluminum Color RAL Color,all Ral Colour Color Coated Steel Coil/ppgi Steel Coil/ppgi Coil
High Light

Color Coated Prepainted Galvanized Steel

,

ASTM Ral3005 Prepainted Galvanized Steel

,

Dx51d Pre Painted Steel Coils

Leave a Message
Product Description
Cold Rolled PE HDP SMP PVDF Dx51d ASTM Ral3005 Prime Quality Color Coated Prepainted Galvanized Steel Coil PPGL PPGI

Color coated plate, also known as PPGI/PPGL . Color coated steel plate is cold rolled steel plate and galvanized steel plate as the base plate, after surface pretreatment (degreasing, cleaning, chemical conversion treatment), in a continuous method of coating (roller coating method), after baking and cooling products. The coated steel plate has light weight, beautiful appearance and good anti-corrosion performance, and can be directly processed, it provides a new raw material for the construction industry, shipbuilding industry, vehicle manufacturing industry, household appliances industry, electrical industry and so on. It has played a good effect of replacing wood with steel, efficient construction, energy saving and pollution prevention.
Product Parameters
Name PPGI /PPGL sheet /coil
Grade: SGCC, Dx51-53D, A653, JISG3303DX51D,SGCC,G550,SPGC
Width 20mm to 1500mm or as clients request
Thickness 0.125mm to 4.0mm
Zinc coating 40g/m2 to 275g/m2
Substrate Cold rolled Substrate / Hot rolled Substrate
Color Ral Color Systerm or as per buyer's color sample
Surface treatment Chromated and oiled, and anti-finger
Hardness Softy , half hard and hard quality
Coil weight 3-12 tons
Coil ID 508mm or 610mm
Packing Export standard packing or clients package
Certificate ISO9001:2008,SGS
Shipment Within10-15 workdays or according to the qty
Price Item FOB,CFR,CIF
MOQ 10 Tons
Port Any Port In China
ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 0

 ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 1
ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 2ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 3
ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 4
ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 5
ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 6ASTM Ral3005 Color Coated Prepainted Galvanized Steel PE HDP SMP PVDF Dx51d 7

1.Hey, you are trading company or factory?

Dear sir,We are Rogo industrial(shanghai) Co.,Ltd. Under the experienced group company J.X.Y

Group. Our mill is in Boxing Shandong the most developed area of producing CRC/GI/PPGI/GL/PPGL.
2.What’s the capacity of your mill?
We own 7 production lines for GI/GL/PPGI/PPGL with the capacity of 1480000MT per year.
3.The size of goods you can produce?

For the size:
Thickness: 0.2-2.0mm


width: 610-1250mm

Zinc coating:35-275g

Painting: 15-20um/5-10um or as you required

Coil weight:3-5MT

CR/Corrugated coil/ sheet:Any size you want
